4G Biometric Fingerprint Scanner , Handheld PDA Barcode Scanner for Parking System
1. RFID handheld terminal particularly designed for financial management, which is able to read tags on bank cash cases and identify working staff; safe and convenient.
2. 5-inch IPS screen with 720*1280 resolution makes it very clear to see.
3. Users can press the keys or touch the screen if they would like to operate.
4. You will find it very comfortable to get hold of it, for the trigger handle is ergonomic.
5. Trigger handle and RFID pistol grip are both detachable, so users can choose as needed.
6. It has a great reading range and a quick reading rate; usually, indoor reading range >22m, outdoor>8m, reading rate>200 tags per second.
| SD50(F) Basic Parameters |
| OS | Android 8.1 |
| CPU | Octa-Core 2.0GHz |
| RAM | 2GB/4RB |
| ROM | 16GB/64GB |
| Expansion | Micro SD (TF) card slot up to 128GB |
| Keypad | 35 buttons |
| Notification | Sound/vibration/LED prompt |
| Audio | Front dual stereo speakers Volume 90db±3db (test distance 10cm) |
| Dimentions | 207*84*20mm |
| Weight( with battery) | 716g |
| Camera |
| Camera | Rear 13MP autofocus and flash light,Front Camera 5MP |
| Focus mode | Autofocus; Fixed focus |
| Flash | Support High Light LED Flash |
| Display |
| Display | 5.0 Inch IPS |
| Resolution | 720*1280 |
| Touch Panel | 5-point capacitive touch screen |
| Power |
| Battery | Master:7000mAh Handle:4000mAh |
| Charging | PE fast charging, ful charging time<4 hours |
| Interface | 2micro SIM cards,1micro SD card slot up to 128GB,USB-Type C, support fast charging, OTG,Support fast charging5V/9A 1.67,charging and bottom USB connector |
| Communication |
| Bluetooth | BT4.1 BLE |
| Wi-fi | IEEE 802.11 a/b/g/n 2.4G 5Gdual frequency |
| WWAN | FDD-LTE B1/B3/B7 TDD-LTE B38/B39/B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8 CDMA1x/CDMA2000 BC0/BC1 |
| GPS Position Module | GPS+BD+GLONASS |
| Performance |
| Operation Temperature | -20℃ ~55℃ |
| Storage Temperature | -30℃ ~+70℃ |
| Humidity | 5%~95%(No condensation) |
| Sealing | IP65 |
| Drop Test | In the operating range, 6 sides can withstand the impact of 1.2meters drop to the concrete floor |
| ESD | ±15kV Air Discharge, ±8kV Contact Discharge |
| Certificate | CCC,CE, ROHS, FCC |
| Extensibility |
| Fingerprint | Crossmatch FBI Fingerprint Scanner |
| UHF RFID Reader | Protocol standard:EPG G2/ISO 18000-6C,Work frequency : China(920-925MHz),North America (902-928MHz),European frequency(865-867MHz),Antenna parameters:4dBi four arm spiral,Power:working voltage3.6V-5V,Radio frequency input:5dBM to 33dBM(1W),1dBM adjustable standby power consumption about 0.25W, the larger is 7.5W (typical 7W),Card reading distance:indoors 22 meters or more, outdoors 8 meters or more. Label speed >200/sec |
| PSAM | Support |
| Sensor | Geomagnetism, acceleration, optical distance |
As a listed company from china manufacturer, we support you:
1. Completely Free SDK and technical support
2. ODM/OEM customization services
3. 13 months warranty and 6 months for the batteries. Exend warranty, it'll cost 10% for each per year.
4. Free maintenance for the replacement of the devices and part of accessories in the warranty .If out of the warranty, you only have to pay the cost.
Parameter of SD50(F) Android Handheld PDA:
4G Handheld PDA Biometrics Fingerprint Scanner/ Barcode Scanner for Parking System
