2D Barcode Scanner Industrial PDA Handheld Android 4G Wifi Magnetic Fixation Devices

Product Categories

Beijing Speedata Technology Co., Ltd

Contact Now

2D Barcode Scanner Industrial PDA Handheld Android 4G Wifi Magnetic Fixation Devices

Name: 2D Barcode Scanner Industrial PDA Handheld Android 4G Wifi Magnetic Fixation Devices
Brand: SPEEDATA
Price: 1 USD

China 2D Barcode Scanner Industrial PDA Handheld Android 4G Wifi Magnetic Fixation Devices wholesale

Brand Name : SPEEDATA

Model Number : KT55

Certification : ISO9001/IP65/1.5M Drop Resistance

Place of Origin : China Mainland

MOQ : 1-5pcs

Payment Terms : T/T, Western Union, MoneyGram,Paypal

Supply Ability : 10000unit/month

Delivery Time : 5-8working days

Packaging Details : Speedata Conventional Packing-1pcs; USB Data Cable-1pcs; Charger-1pcs; Protection Cover-1pcs; Hand Strap-1pcs.

Item Name : Industrial Smartphone PDA

OS : Android 5.1

CPU : Octa-core 1.3Ghz Cortex-A53

Screen : 5.5inch super big AMOLED Screen

WWLAN : 4G LTE

Battery : Rechargeable Li-ion battery 6000mAh

Interface : USB RS232 SPI GPIO

Specification : The Most Thinnest PDA 1CM

Functions : 2D Barcode Scanner

Contact Now

Dual 5.5Inch Android Screens 4G Wifi Smartphone Industrial PDA with Barcode Scanner

KT55 SPEC
Android OS
OS		Android 5.1
CORE
Core	CPU	Octa-core 1.3GHz ARM® Cortex-A53
	WWLAN	FDD B1B3B7 TDD B38B39B40 WCDMA B1B2B5B8 EVDO BC0 GSM B2B3B5B8
	Flash ROM	16GB
	RAM	2GB DDR3
General Configuration
Display	Main Screen	5.5 inch OLED 1920*1080 FHD
Display	Sub-screen	0.91 OLED
Touch screen		Multi-point touch capacitive screen
Fingerprint		YES
GPS		Support GPS/QZSS/SBAS (WAAS/MSAS/EGNOS/GAGAN). Support Full AGPS
Bluetooth		v2.1+EDR / 3.0+HS / v4.0 Low Energy (LE)
WiFi		802.11 a/b/g/n
Protection class		IP65
Drop resistance level		1.5m
Camera (OPTION)	Rear camera	13MP Camera
Camera (OPTION)	Front camera	5MP Camera
Keypad	Front /Side	5 side buttons
Interface	Micro-USB connector	USB2.0 OTG
	SIM card slot	1 standard SIM slot
	SIM card slot	1 Micro SIM slot
	TF card slot	Yes
	power jack	Micro-USB
	Audio Jack	Yes
External Interface	OPTION	USB, RS232, SPI, GPIO
Battery	Type	rechargeable Li-ion battery 6000mAh
	Standby Time	600hours
	Calls Time	Up to 6hours
	Charging Time	5 hours (USB charging)
Physical Characteristics	Dimension	1707913mm
Physical Characteristics	Weight	>250g with battery (according config)
Operating temperature		-20°C to 50°C / -4°F to 122°F
Storage temperature		-30°C to 70°C / -22°F to 158°F
Humidity (non-condensed)		Operating 10% to 90% / Storage 5% to 95%
Electrostatic discharge		± 15 kV air discharge, ± 8 kV contact discharge
EMC regulation		CE
OPTIONS
Appearance color	option	various color options
Wireless charging	option	include Wireless transmitting base.
Far Infrared Meter Reading	option	IEC62056-21(IEC1107) communication protocol
IRIS recognition	option	The recognition distance is less than 20cm
PSAM	option	ISO7816 (SIM card interface)
NFC	option	NFC(Compatible 13.56MHz ISO 14443A ISO15693)
Barcode scanner	option	Honeywell N6603 1D & 2D barcode scanner
Clip device
RFID reader	option 1	LF RFID(134.2KHz, ISO11784/11785, FDX-B/HDX)
	option 2	LF RFID(125KHz)
	option 3	HF RFID(13.56MHz ISO 14443A/B ISO 15693)
	option 4	R2000 UHF RFID 860-960MHz ISO18000-6C (EPC Gen2)
IC card reader(Optional)	option	ISO7816 ID-1
Printer	option	2 inch direct thermal printer
MRZ	option	ICAO Document 9303 / E13B and OCRB fonts
Fingerprint reader	option 1	UPEK TCS1 (meet the FBI’s FIPS-201)
	option 2	UPEK TCS2SS
	option 3	Customized according to customer needs.
Free Extension		Multiple extension interface, such as RS232, GPIO, USB, SPI. You can freely design what you want.
